Application of Inductive Spot Welding Head

Inductive spot welding head is an important component of electronic spot welding machines for paint removal and welding operations. The welding head can be processed into different shapes based on the diameter of the enameled wire being welded and the different workpieces, and can be designed according to customer requirements. Detailed applications include the production and manufacturing of various electronic components with small coils, such as high-frequency communication components, SMT transformers, SMT inductors, micro speakers, inductive IC cards, buzzers, receivers, speakers, headphones, antennas, microphones, sounders, hands-free earphones, vibration motors, micro motors, clock coils, modules, and other small coil electronic components. They can also be welded to the contact points of metal wires Welding of outgoing line contacts such as metal strips, metal sheets, solar cells, telecommunications data lines, etc.

We provide various models of welding heads for different electronic components and welding process requirements.

Special spot welding heads for inductive spot welding machines include flat, inclined, V-shaped, circular, etc. When welding, it has the characteristics of bright, reliable, stable solder joints, and low signal attenuation.

The welding head has superior quality, long service life, and a complete range of specifications and models, which can be customized according to customer samples. According to the different specifications of the spot welding wire diameter and the shape needs of the welding point, different models of welding heads are selected. Spot welding head is a key component of electronic spot welding machine for paint removal and welding work. The welding head can be processed into different shapes according to the diameter of the enameled wire being welded and the different workpieces, and can be designed according to customer requirements.

The inductance spot welding head we produce is heated and cooled together during pressurization, avoiding floating and false soldering at the joint. It is more suitable for hot pressing welding, soldering, and resin bonding of flexible materials and wires. The reproducibility of superior temperature, time and other parameters can achieve the production of high-quality products. The local instantaneous heating method can effectively control the thermal impact on surrounding components. Mainly used for:

1. Hot pressing, soldering, etc. of flexible circuit boards in electronic products such as LCD, PDP, and mobile phones.

2. Soldering of enameled wires such as HDDs, coils, capacitors, motors, sensors, etc.

3. Soldering of cables and connectors inside communication machines such as computers.

4. Soldering of CMOS, CCD, and FPC boards for digital cameras, mobile phones, etc.

5. Resin hot pressing bonding for relays, printers, small cameras, etc.

6. Gold wire hot pressing bonding inside microwave devices.

Our company produces many wholesale hot pressing welding heads, which are specifically used for electronic pulse micro spot welding machines, circuit board repair machines, etc., with advantages such as small welding points, good conductivity, small signal attenuation, and long service life of welding heads.

If you need to purchase, please contact me by email :aria.diao@soucua.com.
